PRESSURE SWITCH SINGLE STAGE SUMO COMPRESSOR FOR 150PSI |
|
|
|
|
NO. |
SPEED |
|
|
CAPACITY RATED PRESSURE |
TANK |
LIST PRICE |
|
Model |
HP |
PHASE |
CLYS |
RPM |
Lit/Min |
CFM |
Kg/cm 2 |
(psig) |
KPA |
(LTRS) |
(RM) |
|
SM-11-1S |
1.5 |
1PH |
1 |
1280 |
116 |
4.1 |
10 |
150 |
798 |
50 |
1,454.00 |
|
SM-22-1S |
2.2 |
1PH |
2 |
940 |
212 |
7.5 |
10 |
150 |
1035 |
100 |
1,841.00 |
|
SM-22-3S |
2 |
3PH |
2 |
940 |
212 |
7.5 |
10 |
150 |
1035 |
100 |
1,928.00 |
|
SM-33-1S |
3 |
1PH |
2 |
1050 |
286 |
10.1 |
10 |
150 |
1035 |
100 |
2,378.00 |
|
SM-33-3S |
3 |
3PH |
2 |
1050 |
286 |
10.1 |
10 |
150 |
1035 |
100 |
2,501.00 |
|
PRESSURE SWITCH SINGLE STAGE SUMO COMPRESSOR FOR 110PSI |
|
|
|
|
NO. |
SPEED |
|
|
CAPACITY RATED PRESSURE |
TANK |
LIST PRICE |
|
Model |
HP |
PHASE |
CLYS |
RPM |
Lit/Min |
CFM |
Kg/cm 2 |
(psig) |
KPA |
(LTRS) |
(RM) |
|
SM-55-180S |
5.5 |
3PH |
2 |
845 |
515 |
18.2 |
7.7 |
110 |
798 |
180 |
4,747.00 |
|
SM-55-250S |
5.5 |
3PH |
2 |
845 |
515 |
18.2 |
7.7 |
110 |
798 |
250 |
5,345.00 |
|
SM-77-250S |
7.5 |
3PH |
2 |
690 |
710 |
25.1 |
7.7 |
110 |
763 |
250 |
6,511.00 |
|
SM-1000-400S |
10 |
3PH |
2 |
920 |
954 |
33.7 |
7.7 |
110 |
763 |
400 |
7,850.00 |
|
SM-1500-400S |
15 |
3PH |
3 |
925 |
1389 |
49.1 |
7.7 |
110 |
763 |
400 |
10,941.00 |
|
MEDIUM PRESSURE 2 STAGE SUMO COMPRESSOR FOR 150 PSI |
|
|
|
|
NO. |
SPEED |
|
|
CAPACITY RATED PRESSURE |
TANK |
LIST PRICE |
|
Model |
HP |
PHASE |
CLYS |
RPM |
Lit/Min |
CFM |
Kg/cm2 |
(psig) |
KPA |
(LTRS) |
(RM) |
|
SM-55-180T |
5.5 |
3PH |
2 |
770 |
450 |
15.9 |
10 |
150 |
1076 |
180 |
5,135.00 |
|
SM-55-250T |
5.5 |
3PH |
2 |
770 |
450 |
15.9 |
10 |
150 |
1076 |
250 |
5,823.00 |
|
SM-77-250T |
7.5 |
3PH |
2 |
950 |
495 |
17.5 |
10 |
150 |
1180 |
250 |
6,632.00 |
|
SM-1000-400T |
10 |
3PH |
3 |
750 |
835 |
29.5 |
10 |
150 |
1180 |
400 |
8,822.00 |
|
SM-1500-400T |
15 |
3PH |
3 |
1150 |
1228 |
43.4 |
10 |
150 |
1180 |
400 |
11,131.00 |
|
